Network Audit Result
This dialog is called from the ENP menu “Tools – Basic TE Configuration – Show Network Audit Result…”.
Purpose
The main purpose of this feature is to display current audit results from the alignment of QoS reference tables over several nodes throughout the network.
The dialog also allows you to export network audit reports to a CSV file.
Dialog image
Network Audit Result
Mandatory entries
Choose whether to display last audit results, or to display reports for export purposes. The selection is done via radio buttons. You need to select either “Last Results” or “Reports”.
• When choosing “Last Results”, only node results and table results are shown.
• When choosing “Reports”, a list of updates (reports) is shown. You can select one of these reports for export to a CSV file.
Optional entries
A node should be selected in order to display the audited reference tables and the related audit status.
Informational content
List of Reports (only available when the “Reports” radio button is selected)
Latest Update | Date and time of the recorded audit. |
List of Node Results
Node | Name of the audited NE. |
NE ID | ID of the node within the audit function. |
NE Version | The specified NE version. The NE version is identified by the node’s NE software name and its version. |
Latest Update | Date and time of the latest update of the reference tables for the respective NE. |
Status | Alignment status of the reference tables for the selected NE. - Aligned: All reference tables are aligned on this NE. - Unaligned: At least one QoS mapping table is not aligned on this NE. - Error: An error has occurred during the alignment. |
List of Table Results
Table | Name of the audited reference table for the selected NE. |
Status | Alignment status of the reference table for the selected NE. - Aligned: All parameters are aligned in the respective mapping table. - Unaligned: At least one parameter is not aligned in the respective mapping table. - Error: There was an error during the alignment of the table, e.g. due to an incompatibility. |
Controls (buttons, menu items, etc.)
Last Results | Select this button to get a list of Table results for each of the audited nodes. |
Reports | Select this button to get a list of Report updates of which the selected report can be exported to a file. |
Export… | Command to export the selected contents to a file. |
? Help | Calls the help viewer and opens this page. |
Close | Closes the dialog. |
