Overview
The overview tab is the dashboard for a quick overview of the network performance status and history. Overviews and diagrams, where appropriate, are shown for the selected time. The overview provides the following graphical views:
• Network,
An overview page with widgets providing graphical overviews on various aspects of network performance, network elements performance, and sections performance.
• Health Monitors, including the tabs
− Performance State,
displaying collected performance data for all Health Monitors,
− Values,
displaying charts for the selected time span (via Global Time Selector) for all Health Monitors,
• Metrics Collections,
providing a chart of the NEs health monitoring status.
Flexible options allow selection of history intervals via the “Global Time selector for all charts”, such as
• Last 24 Hours,
• Last 7 Days,
• Last 30 Days.
